Three-phase flow measurement is a worldwide challenge. After years of dedicated research and development projects, our company has designed, manufactured and put into service a low-cost, highly reliable and high-performance Advanced Three-phase Flow Meter(ATFM). The instrument features advanced intelligence and intelligent algorithms. It adopts data fusion from eight sensors and probes to establish an innovative three-phase flow measurement architecture. This three-phase flow meter boasts compact size, high reliability and low cost, making it easy for widespread deployment.
|
Model |
YC-J-III |
Nominal diameter |
DN50 |
|
Liquid volume |
0~10/20/50/80/150/200 |
Accuracy |
±5% FS |
|
Containing gas |
0-3000 m² |
Accuracy |
±6% FS |
|
Containing water |
0~100% |
Accuracy |
±5% |
|
Pressure |
6Mpa |
Accuracy |
±0.5% FS |
|
Temperature |
-25℃~+100℃ |
Accuracy |
±0.5℃ |
|
Power supply |
220V AC |
Signal output |
Wired/Wireless Remote Transmission |
|
Overall Dimensions |
1050Î300 Î1170mm |
Device interface |
Clamp, thread, flange |
