Sucker rod is one of our main products which built up by the essence of advanced technology from home and abroad. Product categories are organized and manufactured in accordance with API SPEC 11B, SY/T5o29 standards. Using the special processing techniques, we have developed the sucker rod with ultra-high strength, high strength, and high toughness, surface coating material and the HL, HY, KD, D grades.
In addition, we also have rod products with high-strength, high-corrosion resistance in accordance with the non-API design standards for special purposes. As the material used in the sucker rod, we have developed the special material with high-strength and high-corrosion resistance with the Xi'an communication University and cooperated with many larger international manufacturers to produce different rod products with a variety of performance levels. These have been widely adapted by various domestic and overseas fields. Currently, our production capacity for the sucker rod products is about 5 million meters annually.

Main Technical Parameters for Sucker Rod

 Name

 Size

 Grade

Mechanical Properties

Length

(m)

Rm

(MPa)

Rel

(MPa)

A(%)

(200mm)

Z

(%)

Sucker Rods and Pony Rods

16、19、22、25、29、32

K

620~795

415

≥13

≥60

7.62、8.00、9.14、10.00

C

620~795

415

≥13

≥50

D

795~965

590

≥10

≥50

High-strength Anticorrosion Sucker Rods

KD

795~965

590

≥10

≥50

Ultra-high Strength Sucker Rods

H

965~1195

795

≥10

≥45

Main Technical Parameters for Polished Rods

Name

Size

Grade

Mechanical Properties

Length

(m)

Rel

(MPa)

Rm

(MPa)

A

(%)

Z

(%)

Polished Rods-upset on One End

25、29、32、38

H

≥795

965~1195

≥10

≥45

4.0~10.0

D

≥590

795~965

≥10

≥50

Polished Rods-normal Type

H

≥795

965~1195

≥10

≥45

D

≥590

795~965

≥10

≥50

Polished Rods-metal Spray

H

≥795

965~1195

≥10

≥45

D

≥590

795~965

≥10

≥50

Mechanical Property

Grade

Tensile Strength

(Mpa)

Yield

Strength

(Mpa)

Coefficient of

Elongation 200mm

(%)

Section Shrinkage

(%)

AKV

(J)

HL

965 – 1195

≥795

≥10

≥45

≥60

Chemical Composition

Material

C

Si

Mn

Cr

Ni

Mo

Cu

V

P

S

35CrMoA

0.32~0.40

0.17~0.37

0.40~0.70

0.80~1.10

≤0.30

0.15~0.25

≤0.20

---

≤0.025

≤0.025
